IS-103SH

AUTOMATIC BOBBIN EXCHANGING Supplying bobbin from winded-up tail cutting, doffing, transmitting, feeding by air
cylinder operation
AUTOMATIC BOBBIN SUPPLYING Required bobbins are pneumatically feed in the bobbin storage box positioned upper
side of the machine
AUTOMATIC TUCKING-IN Winded-up thread is automatically trucked in the blade chipped groove on the bobbin flange
then tail thread is automatically cut in sequence
TOUCH SCREEN / DIGITAL COUNTER LENGTH-MEASURING Maximize convenience with a simple touch input method,
target take-up length is effectively controlled by pre-set take-up length parameter on the digital counter
AIR DOFFING SYSTEM Enables to supplying bobbins from feeding, transmitting, exchanging with maximum convenience
DROPPER YARN-CUT SENSING Supplying thread breakage is instantly detected by dropper sensing device for immediate
remedial actions
SPEED CONTROLLING Implements the take-up quality most sought after in demand through speed adjustment of
spindles and traverse
